Product technical parameters

1.Product Model WGL-03-93

2.oxygen production 3L/MIN

3.compressed air consumption 45L/min

pressure: 0.22M Pa

4.oxygen purity ≥93%

5.oxygen outlet pressure 60-80Kpa

6.oxygen generator 220 V /50HZ  power ≤250 W

7.oxygen generator size 38x26x73cm

I. APPLICATION AREAS

PSA oxygen generator is favored by users because of its remarkable advantages. It is widely used in metallurgical combustion, chemical industry, environmental protection, building materials, light industry, medical treatment, aquaculture, biotechnology, sewage treatment and other fields.

II. Technical characteristics

Perfect fluency design, optimal use effect;

Reasonable internal components, uniform distribution of airflow, reduce high-speed impact of airflow;

Special protection measures for molecular sieves to extend the service life of molecular sieves;

Simple operation, stable operation, high degree of automation, can be run by no one;

Automatic interlocking oxygen emptying device to ensure product oxygen quality;

III. Working principles

By using the principle of PSA pressure swing adsorption, the nitrogen and oxygen molecules in the air are separated by molecular sieve,

oxygen retention, nitrogen discharge. At room temperature, the power supply can be continuously separated from the air to produce high concentration oxygen under rated oxygen flow.

IV. Material of molecular sieve

A lithium low silicon oxygen molecular sieve (93%±2) has the advantages of high oxygen purity, high production ratio, small mechanical wear and long life.
